Environmental Parameters
Humidity Range Operating	10 - 85% (non-condensing)
Humidity Range Storage	0 - 95% (non-condensing)
Max Operating Temperature	113 °F
Max Storage Temperature	158 °F
Min Operating Temperature	32 °F
Min Storage Temperature	-40 °F
Expansion / Connectivity
Interfaces	4 x SFP/SFP+ ¦ 24 x 10Base-T/100Base-TX/1000Base-T - RJ-45
General
Capacity	Virtual interfaces (VLANs) : 4096 ¦ IGMP snooping entries : 3000
Compliant Standards	IEEE 802.3 IEEE 802.3u IEEE 802.3z IEEE 802.1D IEEE 802.1Q IEEE 802.3ab IEEE 802.1p IEEE 802.3af IEEE 802.3x IEEE 802.3ad (LACP) IEEE 802.1w IEEE 802.1x IEEE 802.1s IEEE 802.1ab (LLDP) IEEE 802.3at
Device Type	Switch - 24 ports - stackable
Dimensions (WxDxH)	17.2 in x 12.2 in x 1.7 in
Enclosure Type	Desktop - 1U
Features	Flow control BOOTP support RARP support ARP support VLAN support auto-uplink (auto MDI/MDI-X) DoS attack prevention DiffServ support store and forward IPv6 support SNTP support Spanning Tree Protocol (STP) support Rapid Spanning Tree Protocol (RSTP) support VLAN Stacking Multiple Spanning Tree Protocol (MSTP) support DHCP snooping Quality of Service (QoS) DHCP server temperature sensor Time Domain Reflectometry (TDR) front to back airflow Per-VLAN Spanning Tree Plus (PVST+) IPv4 support LLDP support Link Aggregation Control Protocol (LACP)
Jumbo Frame Support	9216
MAC Address Table Size	16K entries
Ports	24 x 10/100/1000 + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+
Power	DC -36 -72 V
Remote Management Protocol	SNMP 1 RMON 1 RMON 2 RMON 3 RMON 9 Telnet SNMP 3 SNMP 2c HTTP TFTP SSH SSH-2
Routing Protocol	RIP-1 RIP-2 static IPv4 routing
Power
Power Consumption Operational	100 Watt
Power Device	Power supply
Voltage Required	DC -36 -72 V

Juniper Networks EX3300, 24-port 10/100/1000BaseT with 4 SFP+ 1/10G uplink ports (optics not included) and internal DC power supply The EX3300 line of Ethernet Switches features Virtual Chassis technology to deliver a flexible, cost-effective enterprise access solution for demanding environments that support converged data, voice, and video

Juniper Networks EX3300, 24-port 10/100/1000BaseT with 4 SFP+ 1/10G uplink ports (optics not included) and internal DC power supply The EX3300 line of Ethernet Switches features Virtual Chassis technology to deliver a flexible, cost-effective enterprise access solution for demanding environments that support converged data, voice, and video. Virtual Chassis technology enables up to six interconnected EX3300 switches to operate as a single, logical device, providing enterprises with a level of flexibility and management simplicity normally associated with higher-end access switches. PoE support enables the EX3300 to support networked devices such as telephones, video cameras, and wireless LAN (WLAN) access points.
